Tolerances (Tolerance on Thickness)
| Thickness (mm) |
Tolerance on Thicknes (+/-) for width (mm) |
|
<250 |
<250 to <500 |
<500 to <1000 |
| 0.05 |
0.15 |
0.005 |
0.005 |
- |
| 0.15 |
0.25 |
0.015 |
0.020 |
- |
| 0.25 |
0.40 |
0.030 |
0.040 |
0.040 |
| 0.40 |
0.60 |
0.040 |
0.040 |
0.050 |
| 0.60 |
0.80 |
0.050 |
0.060 |
0.070 |
| 0.80 |
1.00 |
0.060 |
0.070 |
0.080 |
| 1.00 |
1.25 |
0.070 |
0.080 |
0.080 |
| 1.25 |
1.50 |
0.080 |
0.090 |
0.100 |
| 1.50 |
2.00 |
0.090 |
0.110 |
0.120 |
| 2.00 |
2.50 |
0.100 |
0.120 |
0.150 |
| 2.50 |
3.00 |
0.120 |
0.150 |
0.200 |
| 3.00 |
4.00 |
0.150 |
0.170 |
0.200 |
Tolerances on Width
| Condition of Edge |
Width Tolerance of nominal Width(mm) |
|
<250 |
<250 to <500 |
<500 to <100 |
| Mill Edge |
+5 |
+10 |
+20 |
| -0 |
-0 |
-0 |
| Trim Edge |
+5 |
+5 |
+5 |
| -0 |
-0 |
-0 |
Tolerances on Slit Width
| Thickness (mm) |
Width tolerance(+ / -) on nominal width ( mm ) |
|
<150 |
150 < 250 |
250 < 500 |
500 < 1000 |
| 0.60 |
|
0.15 |
0.20 |
0.25 |
0.50 |
| 0.60 |
1.00 |
0.20 |
0.25 |
0.25 |
0.50 |
| 1.00 |
1.50 |
0.20 |
0.30 |
0.30 |
0.60 |
| 1.50 |
2.50 |
0.25 |
0.35 |
0.35 |
0.70 |
| 2.50 |
4.00 |
0.30 |
0.40 |
0.40 |
0.80 |
